1 DNT 47047 - - -

Nut 6x1x5

-

2 RSN 32690 - - -

Split washer 6x11x1,5

-

3 RN 54593 - - -

Washer 6x19x2

-

4 109 BV 55867 - - -

Friction ring for heating control levers

-

5 107 BV 56401 - - -

Heating, ventilation and starter control lever

-

6 107 BV 55688 - - -

Niples on the dashboard air delivery throttle lever

-

7 VN 57637 - - -

Screw 5 x 0.8 x 8

-

8 CN 42802 - - -

Split pin 1,5x25

-

9 2 041 148 810 - - -

Friction ring between heating control lever and spring

-

10 107 BV 55637 - - -

Shaft for heating control lever

-

12 107 BV 57551 - - -

Complete plate for heating control unit

-

13 RN 33895 - - -

Washer 4x7x1 for switch fixing nut

-

14 DNT 47446 - - -

Nut 4x0,7

-

15 VN 32689 - - -

Screw d. 5 MAx8 fix. cable and sheath control throttle convogl. dashboard air

-

16 1 012 042 448 847 - - -

Niples on the frame beams for sheath fixing

-

17 RNT 47074 - - - new

Flat washer Ø 6

$0.75

18 VNT 58411 - - -

Screw for fixing the throttle control knob on the rib

-

19 107 BV 58410 - - -

Knob for throttle control on the rib

-

20 107 BV 53382 107 BV 53544 - - -

Left throttle choke on the rib

Right throttle for air control on the rib

Left throttle choke on the rib<br> <br> Right throttle for air control on the rib

-

21 VNT 49513 - - -

Screw 10 TCPx12 for heating pipe clamps

-

22 FRN 44681 - - -

Clamp fixing radiator water delivery pipe heating right

-

23 107 BV 53316 - - -

Complete radiator for heating system

-

25 FRN 37824 - - -

Clamp for fastening vacuum sleeve Ø 15

-

26 VNT 49217 - - -

Screw Ø 3.58 x 9.52 fixing plate overall and side air intake sleeve

-

27 107 BV 56364 - - -

Gasket for air conveyor on the rib

-

28 107 BV 53318 107 BV 53319 - - -

Air conveyor on the rib - right

Air conveyor on the rib - left

Air conveyor on the rib - right<br> <br> Air conveyor on the rib - left

-

29 VNT 56825 - - -

Screw 6 TCP for fixing the conveyors to the rib

-

30 101/7 BV 52245 - - -

Nut for fan

-

31 107 BV 56216 - - -

Nut gasket

-

32 107 BV 58412 - - -

Fan for snail

-

33 107 BV 53320 - - -

Air conveyor on the left beam

-

33 107 BV 53315 - - -

Air conveyor on the right beam

-

34 VNT 48708 - - -

Screw d. 4 MAx20 for fixing the nut to the fan

-

35 RSN 33189 - - -

Split washer 4x10 for capacitor fixing

-

36 FRN 57598 - - -

Clamp fixing the heating pipes to the frame

-

37 FGN 57669 - - -

Steel braided cable for starter control

-

39 FGN 57260 - - -

1.2x30 steel wire for starter control

-

40 GFN 57259 - - -

Gaine L = 800 pour câble de commande eau chaude

-

43 107 BV 57613 - - -

Niples on the hot water regulating valve for heating

-

44 107 BV 55672 - - -

2-way hot water regulating valve

-

45 107 BV 57131 - - -

Hot water delivery sleeve from the manifold to the valve

-

46 107 BV 57133 - - -

Plate fixing regulator valve to frame

-

47 VNT 48819 - - -

Ø 4,2x19 screw for fixing spring holding plate

-

48 FRN 37825 - - -

Clamp 16 ÷ 25 for fixing air delivery pipes (for USA)

-

49 FRN 57599 - - -

Clamp fixing the heating pipes to the frame

-

50 MN 54688 - - -

Sleeve 14x20x220 from basement pipe to valve

-

51 107 BV 56641 - - -

Butterfly levers on the frame beams

-

52 107 BV 53394 - - -

Butterfly on the fan area beam

-

53 1 012 039 148 869 - - -

Niples for throttle control cable fixing

-

54 RNT 52530 - - -

Even washer Ø 5x11

-

55 109 BV 56581 - - -

Butterfly on the front air intake

-

56 MN 47443 - - -

Sleeve between valve and connecting pipe radiator with exchanger

-

44197 1 012 041 748 818 - - -

Clutch spring for heating control levers

-

Consignment

Consignment

Maserati / Quattroporte I / T-32 - heating and cooling-system
